Swenson Select

Features

• Double acting tailgate with spreader chains provides two way tailgate release
• 34″ wide conveyor moves a variety of materials
• Direct drive hydraulic motor is reliable and easily serviced
• Standard air operated tailgate
• Optional conveyor cover plate
• Pinned in feedgate allows for easy removal when not in use
• Optional front discharge provides increased front tire traction
• Optional high temp belt over chain provides smooth conveyance of most materials including asphalt
• 8 tooth sprocket and 2″ drive/idler shafts provides smooth conveyance of material

Equipment

• Size Specifications: Body Length: 9′ to 16′, Side Heights: 28″ to 44″, Tailgate Heights: 38″ to 54″
• Capacity: 5.0 to 16.5 cubic yards
• Construction: Stainless steel, carbon steel, Corten
• Application Rate: 4′ to 40′ spread pattern, 400 to 900 lbs per lane mile
• Steel Gauges: 7 gauge sides
• Warranty: 1 year
• Options: Pre-wet systems, high temp belt over chain, top screens, double acting cylinder, ladder, dual flow control valve, rear conveyor switch, vibrator, 3 door feedgate
